Flexim Flow Meter Installation Guidelines: Transducer Positioning and Coupling Gel Application
Quick Answer: Transducer position and a uniform coupling gel layer decide whether a clamp-on ultrasonic flow meter reads stable flow data. On horizontal pipes, mount the transducers at the 3 and 9 positions. Apply a 1 to 2 mm gel film with no air bubbles. Send your pipe size, wall thickness, fluid type, temperature, and flow range to Silver Automation Instruments for a quote.
These guidelines apply to Flexim flow meters and Silver Instruments clamp-on ultrasonic flow meters. We see the same installation mistakes on customer sites in Vietnam, Saudi Arabia, Thailand, and New Zealand. A good meter will not read correctly if the transducer position is wrong or the coupling gel is too thick.
Where to Mount Transducers on a Horizontal Pipe
Do not place transducers on the top of the pipe. Gas bubbles collect on the top wall in many liquid lines. Do not place them on the bottom either. Sediment, sludge, and scale settle there. The best mounting is at the 3 and 9 positions. This side mount keeps the ultrasonic path away from gas and solids.
On vertical pipes, the position is less critical because gas and solids move with the flow. But make sure the pipe section is fully flooded. A partially full drain line will not give a valid reading.
Transducer Spacing and Mounting Methods
The transmitter calculates the required spacing distance after you enter the pipe outer diameter, wall thickness, pipe material, liner type, fluid type, and fluid temperature. On Flexim portable meters, the calculated distance appears on the display. Silver Instruments clamp-on meters show the same type of spacing in the setup menu.
Small pipes from DN15 to DN50 often use the V method. The signal bounces off the opposite pipe wall and returns to the second transducer. Larger pipes from DN80 to DN400 often use the Z method with transducers on opposite sides. W method works well for very small pipes or low velocity flows.
Pipe Surface Preparation
A clean pipe surface matters more than many engineers expect. Remove paint, loose rust, mud, and scale before mounting. Use a wire brush or grinder to expose bright metal on steel and stainless steel pipes. After grinding, wipe the surface with a dry cloth. Do not use a solvent that leaves a film because the film can block acoustic contact.
For pipes with thick bitumen coating or concrete liner, remove the coating at the mounting point. Soft outer layers with air pockets do not pass the ultrasonic signal well.
Coupling Gel Application Without Air Gaps
Coupling gel fills the microscopic air gaps between the transducer face and the pipe surface. Air is a strong acoustic insulator. A thin air film of 0.02 mm can reduce the signal by more than half. That is why you need a coupling layer with no bubbles.
Apply a bead of gel to the center of the transducer face. Press the transducer against the pipe with a slight twisting motion. The goal is a 1 to 2 mm uniform layer after pressing. Too little gel leaves air pockets. Too much gel changes the acoustic path and causes unstable readings. Remove excess gel with a plastic scraper or a cloth.
Here is the thing. On a hot pipe above 80°C, standard water based gel dries quickly and loses coupling. Use high temperature coupling grease or solid coupling pads. For pipes from 150°C to 200°C, specify a high temperature coupling paste. Silver Instruments offers clamp-on meters with transducers for pipes up to 200°C.
Signal Strength Check After Installation
After mounting the transducers, check the signal strength on the transmitter. Flexim meters show signal quality in dB or percent. Silver Instruments clamp-on meters show signal strength and sound speed in the menu. In practice, a signal strength below 6 dB often means poor coupling or wrong spacing. Reposition the transducers or reapply the gel if the value is low.
We have seen this on customer sites many times. A small movement of 5 mm along the pip
Common Mistakes in the Field
One mistake is mounting transducers on a rusty or painted surface. Another mistake is using too much coupling gel because the installer wants to be safe. A thick gel layer can stretch the signal arrival time and cause the meter to calculate the wrong transit time difference.
Most engineers skip the pipe wall thickness check. The transmitter spacing calculation depends on the exact wall thickness. If the pipe schedule is wrong by 2 mm, the signal may lock onto noise instead of the true transit time. Measure the pipe wall thickness with an ultrasonic thickness gauge before you enter the value.
How These Guidelines Apply to Silver Instruments Meters
Flexim flow meter installation guidelines for transducer positioning and coupling gel application are close to the rules for Silver Instruments clamp-on ultrasonic flow meters. The acoustic physics is the same. Both require a clean pipe, stable transducer placement, and a thin gel layer free of air bubbles.
If you use Flexim portable meters for flow surveys, you can keep the same mounting setup when you install a fixed Silver Instruments clamp-on meter. The transducer holders, spacing tools, and coupling paste methods transfer well across most clamp-on meter brands.
Industrial Applications
A water utility in Vietnam used a Silver Instruments clamp-on flow meter on a DN300 treated water line. The pipe was old ductile iron with a cement liner. After removing the outer scale and applying a thin gel layer, the meter measured 850 cubic meters per hour with a signal strength of 8.5 dB. The same method works for seawater desalination plants in Saudi Arabia, chemical dosing lines in Thailand, and food processing lines in New Zealand.
For custody transfer or billing applications, we recommend an inline electromagnetic flow meter or Coriolis mass flow meter. But for quick flow checks, leak detection, or retrofits without cutting the pipe, clamp-on ultrasonic meters are the fastest option.
Get a Quote for Your Pipe
To get a clamp-on flow meter quotation from Silver Automation Instruments, send us these details: pipe outer diameter and wall thickness, pipe material, fluid type, fluid temperature, operating pressure, flow range, and the installation environment. Also tell us if the pipe is horizontal or vertical and how much straight pipe is available.
Call Silver Automation Instruments at +86-25-68650347 for technical selection help. You can also message us on WhatsApp at +86-25-52155837 or on WeChat at +86 15365082610. Visit flow-meter.com.au to see clamp-on ultrasonic flow meter models, insertion probes, and inline flow meter options.
FAQ: Flexim Flow Meter Installation Guidelines
Q1. What is the best transducer position for a horizontal pipe?
Mount the transducers at the 3 and 9 positions. This keeps the ultrasonic beam away from air bubbles at the top and sediment at the bottom.
Q2. How thick should the coupling gel layer be?
Use a 1 to 2 mm uniform layer after pressing the transducer onto the pipe. The layer should fill air gaps but not lift the transducer away from the surface.
Q3. Can I reuse coupling gel after the meter is removed?
Do not reuse coupling gel. Old gel collects dust and dries out, which creates air pockets. Remove the old gel and apply fresh gel each time.
Q4. What pipe surface preparation is needed before transducer mounting?
Remove paint, rust, scale, and moisture from the mounting area. Grind rough spots if needed. The surface must be smooth and clean for reliable acoustic contact.
Q5. What signal strength should I expect after installation?
For a good installation, target a signal strength above 6 dB. Values from 8 dB to 10 dB are typical on clean pipes with proper transducer spacing and a thin gel layer.
