Is the nozzle type flowmeter the same as the cone type differential pressure flowmeter?

They are different. A nozzle flowmeter is a differential pressure generating device for measuring flow rate, which can be used in conjunction with various differential pressure gauges or transmitters to measure the flow rate of various fluids in pipelines. The standard spray nozzle throttling device is used in conjunction with a differential pressure transmitter to measure the flow rates of liquids, vapors, and gases. It is widely used in various combustion industries such as petroleum, chemical, metallurgical, power, and light industry. Cone flowmeter is a new type of differential pressure flow measurement device, which uses a unique edge wall gradually contracting throttling method to change almost all the disadvantages of conventional throttling devices. Clear width is a revolutionary achievement of differential pressure flowmeter. Its principle is the same as other differential pressure flow meters, which is the classic principle of energy conservation and flow continuity in closed pipelines, and has self rectification, self-cleaning, and self-protection functions.

2. Types and principles of flow meters

Types and principles of flow meters Flow meters are one of the important instruments in industrial measurement, used to measure the volume or mass of fluid (liquid or gas) flowing through per unit time.

. With the development of industrial production, there is an increasing demand for accuracy and range of flow measurement, resulting in the emergence of various types of flow meters. The following are the types and principles of flow meters classified according to measurement principles:

1. Mechani

cal principles Flow meters Differential pressure flow meters: Using Bernoullis theorem, the flow rate is calculated by measuring the pressure difference of the fluid before and after the throttling device. The throttling device can be an orifice plate, nozzle, etc. Rotary flowmeter: uses the force of fluid on the rotor to rotate it, and calculates the flow rate by measuring the speed or angle of the rotor. Impulse flowmeter: Using the momentum theorem, the flow rate is calculated by measuring the impact force of a fluid on an object. Turbine flowmeter: It uses the force of fluid on the turbine blades to rotate the turbine, and calculates the flow rate by measuring the speed of the turbine. Turbine flowmeter has the characteristics of high measurement accuracy and fast response speed. Vortex flowmeter: uses the vortex frequency generated by the fluid after a specific shaped object (such as a vortex generator) to calculate the flow rate. Vortex flowmeter has the characteristics of wide measurement range and good stability. Positive displacement flowmeter: calculates flow rate by measuring the number of times a fluid flows through a fixed volume within a certain period of time. The volumetric flowmeter has the characteristics of high measurement accuracy and is suitable for measuring high viscosity fluids. Xingyu

2. Electrical Principles Flow Meter Electromagnetic Flow Meter: Using Faradays law of electromagnetic induction, the flow rate is calculated by measuring the induced potential generated by the movement of a fluid in a magnetic field. Electromagnetic flow meters have the characteristics of high measurement accuracy and wide applicability, especially suitable for measuring conductive liquids. Differential capac

Is the nozzle type flowmeter the same as the cone type differential pressure flowmeter?

2. Types and principles of flow meters
