Quick Answer: Palm Oil Flow Meter 50 m³/h Offloading Meter Selection
For a 50 m³/h palm oil unloading station at a mill, you need a meter that handles 40 to 50 cP viscosity at 50 to 60 °C and matches a DN80 or DN100 pipe. The two most reliable options are an oval gear flow meter with 316L rotors and PT100 compensation or a Coriolis mass flow meter for direct mass measurement. Silver Automation Instruments supplies both types with 4-20 mA HART output, ATEX Zone 1 certification, and on-site installation manuals.
Palm Oil Flow Meter 50 m³/h Industrial Mill Offloading Manuals
Mill operators across Malaysia, Indonesia, and Thailand offload crude palm oil from tanker trucks into storage silos every day. The flow rate often sits steady at 50 m³/h. Pressure stays around 6 bar and the oil is heated to roughly 55 °C so it flows without clogging. These are not harsh numbers but the sticky nature of palm oil causes problems for many meter types.
Turbine meters struggle. We have seen a mill in Riau replace three turbine meters in two years because the bearings gum up. Magnetic flow meters are out. Palm oil is not conductive enough. Ultrasonic meters work sometimes but the signal scatters when small air bubbles or fats cling to the pipe wall after washdowns. In practice most engineers end up choosing an oval gear positive displacement meter or a Coriolis mass flow meter.
Oval Gear Flow Meter for Palm Oil at 50 m³/h
The oval gear design handles high viscosity fluids with ease. Our OGM series meter with 316L stainless steel rotors and PEEK bearings is built for this exact job. A DN80 model flows up to 80 m³/h so it runs comfortably at 50 m³/h without pushing the upper limit. The meter body is cast iron or stainless steel depending on your CIP requirements. It comes with an integrated PT100 sensor that corrects volume to a reference temperature. This matters because palm oil volume changes by about 0.07 percent per degree Celsius. Without compensation a 10 °C error can lead to a 7 percent volume misreading in custody transfer.
Output options are pulse, 4-20 mA HART, and Modbus RTU. We provide a detailed offloading manual that covers pipe alignment, strainer mesh size, and bypass loop layout. Most mills install a strainer with 0.5 mm mesh right upstream. The manual also explains how to zero the pulse scaler in the control room using our paperless recorder.
Coriolis Mass Flow Meter Alternative
Some mills prefer a Coriolis meter because it gives kg/h directly. Palm oil is sold by weight in many contracts so this saves time. Our CMF series with a DN50 or DN65 tube handles 50 m³/h with a pressure drop under 0.8 bar. The meter body is 316L with Hastelloy options for high free
Installation Support and Manuals
Every meter we ship to a palm oil mill includes a printed manual in English plus a QR code link to a local language version. Our manuals cover mechanical installation, wiring, startup checklist, and troubleshooting. We add photos from real mill sites. A common mistake is placing the meter too close to the pump discharge. The manual specifies 10 DN straight inlet and 5 DN outlet to calm the flow profile. We also include a blow out procedure for cleaning after batch runs.
FAQ
What is the best flow meter for 50 m³/h palm oil offloading?
An oval gear positive displacement meter with PT100 compensation or a Coriolis mass flow meter. Oval gear offers the best cost to accuracy ratio for custody transfer at this rate.
Can the meter handle palm oil that starts to solidify at lower temperatures?
Yes. We design the meter with a heating jacket option and specify startup procedures in the manual. You circulate warm oil slowly until the meter body reaches 45 °C before full flow.
Do you supply meters with ATEX or IECEx for Zone 1 in a palm oil mill?
Absolutely. Our oval gear and Coriolis meters are available with ATEX II 2G Ex db IIC T4 Gb or IECEx certification. We add cable glands and earth tags per the standard.
What pipe size matches 50 m³/h for palm oil?
Typically DN80 or DN100. We size the meter flange to match your existing pipe. If you send us your pipe schedule we confirm the gasket and bolt set in the quote.
How can I get a price and offloading manual for my specific mill?
Send us your pressure in bar, temperature in °C, pipe size DN, and your flow range. Also mention your location and any certification needs. We return a quote within one working day plus a PDF copy of the installation manual for your review. Contact Silver Automation Instruments at flow-meter.com.au or call our Brisbane office.
Get Your Palm Oil Flow Meter Quote and Manual
We ship oval gear and Coriolis palm oil meters to mills in Indonesia, Malaysia, Thailand, Colombia, and Nigeria. Send your pressure (bar), temperature (°C), pipe size (DN), and flow range. Tell us if you need ATEX or IECEx. We include the full offloading manual as a PDF with your quotation. Reach out through flow-meter.com.au or call Silver Automation Instruments directly.
