Frequency Output Flow Meter Processing: Interfacing Raw Sensor Pulse Signals with High-Speed PLC Inputs
Quick Answer: Frequency output flow meters send a pulse train proportional to flow rate or total volume. High-speed PLC inputs must match the pulse amplitude, frequency range, minimum pulse width, and wiring type. Configure a hardware high-speed counter, set the input filter below the minimum pulse width, and scale the count with the correct K-factor.
What Raw Frequency Output Looks Like
A frequency output flow meter does not need a 4-20 mA analog loop. It sends pulses. Each pulse represents a small volume. The PLC counts pulses over time. Flow rate is the frequency in Hz. Total volume is the accumulated pulse count divided by K-factor.
The raw signal may be an NPN open collector, a PNP open collector, a magnetic pickup coil, a reed switch, or a Hall effect output. NPN open collector is common on oval gear flow meters and small turbine meters. The sensor pulls the signal to 0 V when active. The PLC input or an external resistor pulls the line to 24 V when idle. Magnetic pickup outputs are AC sine waves and often need a signal converter before a digital PLC input.
High-Speed PLC Inputs: Practical Checkpoints
Standard PLC digital inputs have a 5 to 10 ms filter. They are fine for limit switches. They miss pulses above 50 to 100 Hz. A hardware high-speed counter input is different. Many compact PLCs have dedicated HSC inputs. Typical models accept 30 kHz to 200 kHz. For example, a Siemens S7-1200 high-speed counter can read 100 kHz with a 24 V single-phase input. A Mitsubishi FX5U high-speed counter can go up to 200 kHz on selected channels. Check the exact input type before wiring.
Two things matter first. The input threshold voltage. A 12 V pulse may not reliably turn on a 24 V PLC input. The minimum pulse width. At 5 kHz with 50 percent duty cycle, the period is 0.2 ms. The high time is 0.1 ms. If the input filter is set to 0.2 ms, the pulse disappears. Also check the input current. Open collector transistors have a maximum current, often 10 to 50 mA. Do not exceed it.
Signal Conditioning Between Flow Meter and PLC
Because an NPN open collector does not drive the line high, the external resistor is not optional. Without it, the PLC input floats. For NPN pulse output, use a pull-up resistor from the signal wire to 24 V DC. The resistor value depends on cable length, PLC input current, and switching speed. A 2.2 kΩ resistor at 24 V gives about 11 mA. That works for many panel runs under 30 m. A 1 kΩ resistor gives about 24 mA and is faster on longer cable runs. Check the sensor current rating first.
For PNP pulse output, the sensor sources current to the PLC input. The input common must be wired to 0 V. For magnetic pickup or low-level AC signals, use a frequency converter module or a dedicated counter card with AC input capability. For reed switch outputs, set a small debounce or digital filter. Reed contacts bounce and create extra pulses at low flow.
Use shielded twisted pair cable. Ground the shield at the PLC panel only. Keep pulse signal wiring away from VFD output cables and motor power leads. We have seen noise on customer sites many times. A paint plant in Vietnam had random totalizer jumps because the pulse cable ran next to a mixer drive cable. Moving the cable solved it.
Scaling Frequency to Flow Rate and Total
Every pulse output flow meter has a K-factor. Check the unit. It may be pulses per liter, pulses per gallon, or pulses per kg. For example, a s
For totalizing, use the hardware counter accumulated value. Total volume equals count divided by K-factor. If the K-factor is 200 pulses per liter and the counter reads 50000 pulses, total volume is 250 L. Set the counter overflow handling carefully in the PLC program.
Field Problems We See in Southeast Asia, Oceania, Latin America, and Africa
A wastewater plant in Vietnam used a 12 V pulse from an oval gear meter on a 24 V input. The threshold was 18 V, so low counts appeared only at high flow. We installed a 2.2 kΩ pull-up to 24 V. Counts became stable.
A diesel depot in Chile had a turbine meter with NPN pulse output. The PLC input was set to PNP sourcing. No count appeared. The wiring was changed and the high-speed counter read the full flow range.
A water treatment plant in Malaysia set the digital input filter to 10 ms. It missed pulses above 50 Hz. The PLC program looked correct. But the hardware filter was the problem. We set the input filter to 0.05 ms and the totalizer matched the mechanical register.
Silver Instruments Pulse Output Flow Meters
Silver Automation Instruments supplies pulse output options on many flow meters. Our vortex flow meter for steam and gas can provide a 24 V NPN or PNP pulse output from 0 to 5000 Hz. Our oval gear flow meter for diesel and oil can provide a reed switch or Hall effect pulse output for low-flow batching. Our electromagnetic flow meter can include a configurable pulse output for water and wastewater. Our Coriolis mass flow meter can output frequency proportional to mass flow for chemical and food batches.
In practice, the right model depends on fluid, line size DN, flow range, temperature, pressure, and PLC input type. Send us these details before ordering. We will confirm the output type, K-factor, and cable length.
FAQ
Q: Can a standard PLC digital input read a flow meter pulse? A: Only at very low frequency. Most standard inputs filter at 5 to 10 ms. Use a dedicated high-speed counter input for anything above 50 to 100 Hz.
Q: What pull-up resistor value should I use for an NPN pulse output? A: Start with 2.2 kΩ at 24 V DC. For longer cable runs or higher frequency, use 1 kΩ if the sensor current rating allows it. Check the minimum pulse width.
Q: Why does my PLC sometimes skip counts at high flow? A: Check the input filter time, input threshold voltage, and cable noise. The filter may be too high or the pulse amplitude may be too low.
Q: How do I convert pulse frequency to flow rate? A: Flow rate in L/min equals frequency in Hz times 60 divided by K-factor in pulses per liter. Confirm the K-factor unit before scaling.
Q: Can Silver Instruments configure the pulse output for my PLC? A: Yes. Send us your flow range in kg/h or L/min, pipe size DN, fluid, pressure bar, temperature °C, and PLC input type. We will set the output type and K-factor.
Quote and Signal Check
Send us your pressure in bar, temperature in °C, pipe size DN, and flow range. We will recommend a pulse output flow meter with the right frequency range for your high-speed PLC input. Contact Silver Automation Instruments at Tel: +86-25-68650347. Whatsapp: +86-25-52155837. WeChat: +86 15365082610. For product pages, visit flow-meter.com.au.
