What are the measurement ranges of vortex flowmeters?

1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;

2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;

3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15

1.2-6; DN20

1.5---10； DN25：2---16； DN32

1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130； DN100：18---160； ..... Gas measurement: (unit: m3/h): DN15:4--28; DN20：6---40； DN25：8---50； DN32：15---150； DN40：18---180； DN50：25---480； DN65：50---500； DN80：80---800； DN100：120---1200； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangqiang Automation Technology Co., Ltd.... Www.qszdh.com

2. How much does a vortex flowmeter with TS certificate cost? To understand these points, the price of vortex flowmeters with TS certificates cannot be directly determined. It needs to be determined based on specific selection and comprehensive evaluation of operating parameters. The following are the key factors and selection suggestions that affect prices: Measurement media and operating parameters. The measurement media of vortex flowmeters include steam, compressed air, nitrogen, carbon dioxide, mixed gases, and liquids. The density, viscosity, and other characteristics of different media will affect sensor selection and material costs. At the same time, it is necessary to clarify parameters such as pressure, temperature, and flow range. For example, special materials (such as stainless steel) and sealing structures are required for high-temperature and high-pressure working conditions, which significantly increases costs. Taking the LUB series as an example, it supports DN15-DN500 caliber with an accuracy level of 1.0, but the specific model needs to be matched according to parameters such as medium flow rate and pipeline size. Image: LUB series vortex flowmeter supports multi-media measurement function configuration requirements. Anti vibration performance: If there is mechanical vibration in the working condition (such as near the pump room or compressor), a model equipped with DSP signal processing circuit and anti vibration algorithm should be selected to ensure stability by shielding interference signals. This type of technology will increase costs. Explosion proof performance: In flammable and explosive environments (such as chemical and oil and gas fields), explosion-proof flow meters should be selected and certified with explosion-proof certificates. The shell material and circuit design should meet explosion-proof standards, and the price should be higher than that of ordinary types. Power supply mode: Supports different modes such as 24V DC, 220V AC, or battery power supply. Special power supply requirements may affect hardware configuration costs. TS Certificate and Compliance Cost TS Certificate (Special Equipment Supervision and Inspection Certificate) is a mandatory certification for vortex flowmeters used in special equipment suc
